POSITIONING
Channels 1408
GPS L1 C/A,L1C, L2P(Y), L2C, L5
GLONASS G1,G2,G3*
BEIDOU B1L,B2L,B3L,B1C,B2a,B2b*
GALILEO E1, E5a, E5b, E6*
QZSS L1,L2C,L5
Cold Start <12s
Initialization Time <5s
Initialization Reliability >99.9%
ACCURACY
Static Accuracy H:±2.5mm+0.5ppm
V:±5.0mm+0.5ppm
RTK Accuracy H:±8.0mm+1ppm
V:±15.0mm+1ppm
Time Accuracy 20ns
Update Frequency 20Hz
POWER
Battery Built-in Battery,6800mAh 7.2V
Duration ≥18.5h
Input 5V/2A DC
PHYSICAL
Material Magnesium alloy main body. ABS/PC top cover
Dimensions 130mm*130mm*70mm
Weight 750g
OPERATION
Button Power Button
Indicator Satellite,Datalink, Power
SYSTEM
Operation System Linux
Memory 8GB Internal Storage
Bluetooth V5.0, BLE
WIFI 802.11a/b/g/n
4G Network LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/
B13/B19/B20/B25/B26/B28
LTE TDD: B38/B39/B40/B41
UMTS: B1/B2/B4/B5/B6/B8/B19
GSM: B2/B3/B5/B8
Internal UHF Power: 1W
Frequency: 410~470MHz
Protocol: Gintec Work、TrimTalk450s(T)、TrimMark III、SOUTH、PCC-EOT、Hi-Target、GeoTalk、GeoMark、SATEL
Tilt Survey IMU Tilt Survey Compatible with SurPad
CAMERA
2Mega CMOS image sensor
Optical Format 1/5 inch
Pixel Size 1.75um*1.75um
Active Pixel array 1616*1232
ENVIRONMENT
Operation Temperature -30℃~+65℃
Stock Temperature -40℃~+80℃
Waterproof Dustproof IP67 Standard
Shock and Vibration Withstanding 2m pole drop onto the cement ground
Humidity 99.9%
