Technical Data
| Cover Measuring Range | Up to 185 mm (7.3“) |
| Cover Measuring Accuracy | ± 1 mm to ± 4 mm (0.04” to 0.16”) |
| Measuring Resolution | Depending on diameter and cover |
| Path Measuring accuracy on smooth surface | ± 3 mm (0.12”) + 0.5% to 1.0% of measured length |
| Display | 7” colour display 800x480 pixels |
| Diameter Measuring Range | Up to 63 mm (2.5“) |
| Diameter Measuring Accuracy | ± 1 bar size |
| Memory | Internal 8 GB Flash memory |
| Regional Settings | Metric and imperial units and multi-language supported |
| Battery | Lithium Polymer, 3.6 V, 14.0 Ah |
| Battery Lifetime | > 8h (in standard operating mode) |
| Mains | 9 V – 15 V / 2.0 A |
| Weight (of display device) | about 1'525 g (incl. Battery) |
| Operating temperature | 0°C – 30°C (Charging*, running instrument) 0°C – 40°C (Charging, instrument is off) -10°C – 50°C (Non-charging) |
| Humidity | < 95 % RH, non condensing |
| IP Classification | IP54 |
| Standards and Directives | CE certification |
*charging equipment is for indoor use only (no IP classification)
Warranty
- Standard 2-year limited warranty on electronic parts
- Optional extended warranty periods up to 3 additional years
